       Leaking strut is covered by 1-year warranty.
       For extended warranty service to 2 years with extra cost, please contact our sole agent/dealers.
Drag Racing

The coilovers are specially designed for 0~400 drag racing such as FWD, RWD or 4WD models. The setting allows vehicle to change the front and rear weight according to the transmission wheel in instant driving, and force the transmission tire having greater compression, which can reduce the idle time of wheel and improve the stability of the vehicle under high speed.

Top level of damping setting for drag racing
Ride height adjustable
30-level damping adjustment
98% of McPherson coilovers are designed with camber adjustable to enhance handling for front and rear top mount
One-year warranty; new replacement for leaking strut
Do not recommended for use general streets purpose
 All applications listed on our website are for 2WD model unless we specify 4WD




Aluminum Top Mount (A6061)
Most of the coilovers come with Pillowball top mount in front and rear, allowing you to experience superb control which cannot be comparable to the rubber top mount. More than 98% of the Pillowball top mounts on the McPherson design coilovers are camber adjustable.
Mono-tube Design
The Mono-tube design of strut are oil and gas separated, in order to avoid coilovers oil deteriorate for longer life and keep it with stable damping.
Fully-adjustable Lower Mount
With movable design, both ride height and preload can be adjusted by adjusting the lower mount.
McPherson lower mount

The iron material (SPHC-C) increases the strengths. Avoid the unusual displacement caused by a span of driving after wheel alignment and improving the lower mount deformation resulted from turning pressure.

Wishbone lower mount

Because there is no turning pressure, aluminum material (A6061) is adopted for wishbone lower mount, having ability to reduce weight and dissipate heat effectively.
Damping Adjustable
The 0~400 type has 30 level damping adjustment, which offers the best performance even under different road conditions. The strut uses needle valve to have linear damping adjustment at each level.
Anti-rust
All threaded parts are coated with Fluorine to prevent corrosion and adherence. Besides, lower mounts are anodized. All metal parts are tested by salt spray test.
Coil Spring
The 0~400 type damper is matched with prefect spring rate. We have different spring settings for FWD, RWD and 4WD models.
Forged Iron Locking Ring
Made of iron (1008A) and then produced by high-pressure forging. It has excellent strength and prevent McPherson lower mount loosening when turning. It is absolutely necessary for safety concerns.
Spring Washer
The piece put between the spring and the locking ring called Iron washer. It can eliminate unusual noises efficiency and allow a vehicle to move more smoothly when turning.

This coilovers kit is specially designed for 0-400 drag racers. Most of the front or rear coilovers come with Pillowball top mount to increase vehicle stability and feel the excellent handling. More than 98% of the McPherson design is available for camber adjustable. However, by its performance, it’s easier to create unusual noise. As a premise, all racing coilovers are designed to enhance the best result, so the product performance must be consumed and are not recommended for general road use.

The pillowball top mount is able to adjust camber degree and increase stability and handling of your vehicle by 10%. However, the pillowball might be prone to creating slight amount of noise over big bumps, and this does not cover any warranty.
Please answer all questions below and send it back to us, your personal custom coilover kit will be made base on the info provided.
Name :
E-mail address :
Tel :
Vehicle Make :
Model :
Year :
What is your vehicle's horse power?
HP
What is your vehicle's weight? ?Front:
kgs (
lbs), Rear :
kgs (
lbs)
How's the weather?
A find day
A rainy day
What type of racing event do you participate in?
Gravel Rally
Tarmac Rally
Drifting
Track
Other
What is your tire camber degree? ?Front:
degree , Rear :
degree
What is your tire toe-in? ?Front:
Rear :
What is your tire toe-out??Front:
Rear :
What is your tire brand? ?
What type of your tires is?
Street tire
Slick tire with lines (soft compound tire)
Racing slick
Rally tire
What is your tire size?
15"
16"
17"
18"
19"
Other
What is your sway bar size? ?Front:?
mm , Rear : ?
mm
Has the off-set of your wheel been modified?
YES, front off-set
, rear off-set
Is there any spacer to be bolted into your wheel?
YES, front
, rear
mm
Does your vehicle have any frame welding?
YES
NO
